37
IV-2-2. LAN Port
The “LAN Port” page allows you to
configure the settings for your access
point’s two wired LAN (Ethernet) ports.
Identifies LAN port. USB is the LAN port
attached via mini USB adapter.
Enable/disable specified LAN port.
Select a speed & duplex type for specified LAN
port, or use the “Auto” value. LAN ports can
operate up to 1000Mbps and full-duplex
enables simultaneous data packets
transfer/receive.
Enable/disable flow control. Flow control can
pause new session request until current data
processing is complete, in order to avoid
device overloads under heavy traffic.
Enable/disable 802.3az. 802.3az is an Energy
Efficient Ethernet feature which disables
unused interfaces to reduce power usage.
