20
III-3. T-Rail Mount
To mount the access point to a T-Rail, please follow the instructions below
and refer to diagram C, D & E.
1. Select the correct size T-Rail bracket from the two sizes which are
included in the package contents.
2. Attach the T-Rail bracket to the ceiling mount using the included screws x
2 as shown in i.
You can use the included bracket and longer screws If you need
more space between the access point and the T-Rail.
3. Attach the access point to the ceiling mount bracket by aligning the
grooves in the access point to the ceiling mount, as shown in ii.
4. Secure the access point firmly in place using the included screw as shown
in iii.
5. Clip the access point onto your T-Rail using the now attached T-Rail
bracket.
