IV-2-3. VLAN
The “VLAN” (Virtual Local Area Network)
enables you to configure VLAN settings. A
VLAN is a local area network which maps
workstations virtually instead of physically and allows you to group together
or isolate users from each other. VLAN IDs 1 – 4095 are supported.
VLAN IDs in the range 1 – 4095 are supported.
VLAN Interface
Wired LAN
Port/Wireless
Identifies LAN port number and wireless SSIDs.
USB is the LAN port attached via mini USB
adapter.
VLAN Mode
Select “Tagged Port” or “Untagged Port” for
specified LAN interface.
VLAN ID
Set a VLAN ID for specified interface, if
“Untagged Port” is selected.
Management VLAN
VLAN ID
Specify the VLAN ID of the management VLAN.
Only the hosts belonging to the same VLAN can
manage the device.
