Edimax CAP1750 User Manual

26
System
Model
Displays the model number of the access
point.
Product Name
Displays the product name for reference,
which consists of “AP” plus the MAC address.
Uptime
Displays the total time since the device was
turned on.
Boot From
Displays information for the booted
hardware, booted from either USB or internal
memory.
Firmware Version
Displays the firmware version.
MAC Address
Displays the access point’s MAC address.
Management VLAN
ID
Displays the management VLAN ID.
IP Address
Displays the IP address of this device. Click
“Refresh” to update this value.
Default
Gateway
Displays the IP address of the default
gateway.
DNS
IP address of DNS (Domain Name Server)
DHCP Server
IP address of DHCP Server.
Wired LAN Port Settings
Wired LAN Port
Specifies which LAN port. USB is the LAN port
attached via mini USB adapter.
Status
Displays the status of the specified LAN port
(connected or disconnected).
VLAN Mode/ID
Displays the VLAN mode (tagged or untagged)
and VLAN ID for the specified LAN port. See
IV-2-3. VLAN
Wireless 2.4GHz (5GHz)
Status
Displays the status of the 2.4GHz or 5GHz
wireless (enabled or disabled).
MAC Address
Displays the access point’s MAC address.
Channel
Displays the channel number the specified
wireless frequency is using for broadcast.
Transmit Power
Displays the wireless radio transmit power
level as a percentage.
RSSI
Displays Received Signal Strength Indicator.
