Edimax CAP1750 User Manual

27
Wireless 2.4GHZ (5GHz) / SSID
SSID
Displays the SSID name(s) for the specified
frequency.
Authentication
Method
Displays the authentication method for the
specified SSID. See IV-3. Wireless Settings
Encryption Type
Displays the encryption type for the specified
SSID. See IV-3. Wireless Settings
VLAN ID
Displays the VLAN ID for the specified SSID.
See IV-2-3. VLAN
Additional
Authentication
Displays the additional authentication type for
the specified SSID. See IV-3. Wireless Settings
Wireless Client
Isolation
Displays whether wireless client isolation is in
use for the specified SSID. See IV-2-3. VLAN
Wireless 2.4GHZ (5GHz) / WDS Status
MAC Address
Displays the peer access point’s MAC address.
Encryption Type
Displays the encryption type for the specified
WDS. See IV-3-1-4. WDS
VLAN Mode/ID
Displays the VLAN ID for the specified WDS.
See IV-3-1-4. WDS
Refresh
Click to refresh all information.
Extender Mode:
Wireless 2.4GHZ (5GHz) / SSID
Connection Status
Current status of the repeater’s connection.
Source SSID
Displays the SSID name(s) for the repeater’s
