Edimax CAP1750 User Manual

66
RADIUS Type
Select “Internal” to use the access point’s
built-in RADIUS server or “external” to use an
external RADIUS server.
RADIUS Server
Enter the RADIUS server host IP address.
Authentication
Port
Set the UDP port used in the authentication
protocol of the RADIUS server. Value must be
between 1 – 65535.
Shared Secret
Enter a shared secret/password between 1 –
99 characters in length. This should match the
“MAC-RADIUS” password used in IV-3-1-3-6 or
IV-3-2-3.
Session Timeout
Set a duration of session timeout in seconds
between 0 – 86400.
Accounting
Enable or disable RADIUS accounting.
Accounting Port
When accounting is enabled (above), set the
UDP port used in the accounting protocol of
the RADIUS server. Value must be between 1 –
65535.

Edimax CAP1750 Specifications

General

Brand	Edimax
Model	CAP1750
Category	Wireless Access Point
Language	English
