18 Installation and Service Guide: Printer Controller EB-34
Installing Hardware
2 Enter SP mode on the copier and specify the correct SP setting to enable communication between the copier and
the EB-34.
The following SP settings are needed for the EB-34:
• SP5193-001:[1]
• SP5895-001:[1]
• SP5895-002:[0]
• SP5985-001:[1]
• SP4-201-011[1]
• SP4-201-012[1]
3 Make sure that the EB-34 and the copier are powered off.
4 Connect the copier interface cable (crossover Ethernet cable) from the lower Ethernet port on the EB-34 connector
panel to the copier (see Figure 6 on page 34).
To verify the cable type, align the connectors on each end of the cable as shown in Figure 3. On a straight-through
cable, the wire arrangements are identical on both ends; on a crossover cable, the wire arrangements are different.
Caution:The copier interface cable included with the EB-34 is a crossover Ethernet cable that connects to the
lower (crossover) Ethernet port on the EB-34 connector panel. The network cable at the customer site is a
straight-through Ethernet cable that connects to the upper (straight-through) Ethernet port on the EB-34
connector panel. The cables look similar, but are not interchangeable. Make sure that you connect the cables to
the correct ports (see Figure 6 on page 34).
