69 Installation and Service Guide: Printer Controller EB-34
Replacing Parts
9 Remove the hard disk drive from the hard disk drive bracket and place it in an antistatic bag.
Do not touch the drive with magnetic objects (such as magnetic screwdrivers), and avoid placing items such as
credit cards and employee ID cards that are sensitive to magnets near the hard disk drive.
Replacement hard disk drives are not shipped with system software preinstalled. After you install the drive, you must
install the appropriate system software.
To replace the hard disk drive
1 If you are installing a new hard disk drive, unpack the drive.
Do not drop, jar, or bump the hard disk drive. Do not touch the hard disk drive with magnetic objects or place
objects sensitive to magnets near the hard disk drive.
1 Screw (1 of 4)
2 Hard disk drive
3 Hard disk drive bracket
Caution:îDo not unscrew the screws on the hard disk drive cover. Loosening these hard disk drive screws
breaks the seal and voids the hard disk drive warranty.
Caution:îDo not install a new hard disk drive and a new motherboard at the same time. If you suspect that the
EB-34 needs a new hard disk drive and a new motherboard, first install the new hard disk drive and install system
software (see page 78), and then install a new motherboard (see page 46).
