EMC VNX VG2 - Page 222

EMC VNX VG2/VG8 Gateway Configuration Setup Guide
222
NAS Install Options
EMC CONFIDENTIAL
e. Enter the domain and hostname for the Control Station. Optionally, enter
secondary and tertiary nameserver IP addresses. Tab to Ok and press Enter.
Figure 143 Example of Configure Network window
The system detects the number of Data Movers and the backend type of your
system.
8. If prompted (Figure 144):
a. Enter the values for the IP addresses of SP A and SP B in the designated fields.
Obtain these values from the “VNX boot array worksheet” on page 276.
b. If security is initialized on the backend, enter the administrator login and
password for the VNX array. Otherwise, leave these fields blank.
c. Tab to Ok and press Enter. The system will now verify the IP addresses.
Note: This prompt is not displayed for gateway systems that are using a Symmetrix
backend for the boot array.
Figure 144 VNX SP settings
