Express Install for File OE Release 7.1 or higher
221
NAS Install Options
EMC CONFIDENTIAL
c. The Configure TCP/IP dialog box appears (Figure 141). To make a selection,
tab to a checkbox and press Enter. Valid selections include:
–IPv4
or
–IPv4 and IPv6 (you must select both checkboxes!)
Tab to Ok and press Enter.
Figure 141 Configure TCP/IP
Note: If you select IPv4 and IPv6, you will be prompted to enter IP addresses in the
IPv6 format.
d. Enter the port IP address, netmask, default gateway IP address, and primary
nameserver IP address (Figure 142). Tab to Ok and press Enter.
Figure 142 Example of Configure TCP/IP window
The system displays the Configure Network dialog box (Figure 143 on
page 222).
