Emerson CW026 - Figure B-1 Liebert Air Economizer Ducting Data

Optional Liebert Air Economizer™ for Liebert CW
Liebert
®
CW
™
System Design Manual 96
Figure B-1 Liebert Air Economizer ducting data
Liebert
Unit
(Front)
Plenum
ROOM RETURN
OUTSIDE
AIR ENTRY
Return Air Sensors
(Field install above damper)
Supply Air Limit Thermistor
(Field install under floor)
Outdoor Air Sensors
(Field install inside duct)
Filter
(by others)
Outdoor Opening
(by others)
Outdoor Relief Opening
(by others)
Room Relief Air Discharge
(Sized and provided by others)
RELIEF AIR
Outside Air Duct
(by others)
DPN001333
Rev. 0
