Emerson CW026 - Figure A-2 Anchor Detail-Seismic Anchorage Rigid Floor Stand, Downflow, CW026 - CW181

Optional Configuration for Liebert CW Seismic Application
Liebert
®
CW
™
System Design Manual 86
Figure A-2 Anchor detail—Seismic anchorage rigid floor stand, downflow, CW026 – CW181
Model Number
Dimensions in. (mm)
Anchor
SizeABCD
CW026, CW038, CW041 46.5 (1181)
42.3 (1073)
3.0 (76) 4.0 (102)
1/2
CW051, CW060 70.5 (1791)
CW076, CW084 95.5 (2426)
4.0 (102) 6.0 (152)
CW089, CW106, CW114
118.5 (3010)
CW146, CW181 54.3 (1378) 6.0 (152) 8.0 (203)
Anchor bolt sized per Hilti Kwik Bolt TZ carbon and stainless in concrete, ICC ESR-1917.
Alternates are subject to review by Emerson or engineer of record.
ANCHOR DETA IL
TYPICAL 6 PLACES
*MIN. EMBEDMENT
*MIN. HOLE
DEPTH
*MIN. PAD
THICKNESS
FLOOR ANCHORING DIMENSIONS
1/8" (3mm)
FIELD WELDING OF UNIT TO FLOORSTAND
UNIT MUST BE WELDED TO FLOORSTAND TO MAINTAIN CERTIFICATION
ANSI B18.22.1
TYPE A, SERIES W PLAIN
WASHER REQUIRED AT
EACH ANCHOR LOCAITON
* SPECIFIED BY ENGINEER OF RECORD
A
A/2
1.0"
25mm
TYP.
B
3.5"
89mm
TYP.
1.8"
44mm
TYP.
2.8"
70mm
TYP.
C
C
D
D
C
C
H
5.6"
143mm
2.0"
51mm
2.5"
64mm
MIN. EDGE
DISTANCE
DPN003209
Pg. 3 Rev. 2
