3.0 Electrical Data
Table 3-1 Electrical data, Liebert CW with EC fans, 60Hz
Models Volts
Reheat/Humidifier No Reheat/Humidifier Reheat/No Humidifier No Reheat/No Humidifier
208 230 380 460 575 208 230 380 460 575 208 230 380 460 575 208 230 380 460 575
CW026
FLA 50.3 46.5 24.7 23.0 20.6 22.5 20.3 11.0 9.8 10.6 37.0 35.4 18.6 17.2 13.2 9.2 9.2 4.9 4.0 3.2
WSA 62.9 58.1 30.9 28.8 25.8 28.1 25.4 13.8 12.3 13.3 46.3 44.3 23.3 21.5 16.5 11.5 11.5 6.1 5.0 4.0
OPD70 60 3530303030151515 45 45 2020152020151515
CW038
FLA 64.1 59.4 31.6 29.5 25.7 22.5 20.3 11.0 9.8 10.6 50.8 48.3 25.5 23.7 18.3 9.2 9.2 4.9 4.0 3.2
WSA 80.1 74.3 39.5 36.9 32.1 28.1 25.4 13.8 12.3 13.3 63.5 60.4 31.9 29.6 22.9 11.5 11.5 6.1 5.0 4.0
OPD90 80 4040353030151515 70 70 3530252020151515
CW041
FLA 64.1 59.4 31.6 29.5 25.7 22.5 20.3 11.0 9.8 10.6 50.8 48.3 25.5 23.7 18.3 9.2 9.2 4.9 4.0 3.2
WSA 80.1 74.3 39.5 36.9 32.1 28.1 25.4 13.8 12.3 13.3 63.5 60.4 31.9 29.6 22.9 11.5 11.5 6.1 5.0 4.0
OPD90 80 4040353030151515 70 70 3530252020151515
CW051
Downflow
FLA 98.7 91.3 47.4 45.3 — 43.2 38.8 20.0 19.1 — 72.1 69.1 35.2 32.4 — 16.6 16.6 7.8 6.2 —
WSA 123.4 114.1 59.3 56.6 — 54.0 48.5 25.0 23.9 — 90.1 86.4 44.0 40.5 — 18.7 18.7 8.8 7.0 —
OPD 125 125 60 60 — 60 45 30 25 — 100 90 45 45 — 20 20 15 15 —
CW051
Upflow
FLA 100.5 93.1 49.4 47.1 40.0 45.0 40.6 22.0 20.9 19.9 73.9 70.9 37.2 34.2 26.5 18.4 18.4 9.8 8.0 6.4
WSA 125.6 116.4 61.8 58.9 50.0 56.3 50.8 27.5 26.1 24.9 92.4 88.6 46.5 42.8 33.1 20.7 20.7 11.0 9.0 7.2
OPD 150 125 70 60 60 50 50 25 30 25 100 90 50 45 35 25 25 15 15 15
CW060
Downflow
FLA 112.6 104.3 54.3 51.8 — 43.2 38.8 20.0 19.1 — 86.0 82.1 42.1 38.9 — 16.6 16.6 7.8 6.2 —
WSA 140.8 130.4 67.9 64.8 — 54.0 48.5 25.0 23.9 — 107.5 102.6 52.6 48.6 — 18.7 18.7 8.8 7.0 —
OPD 150 150 70 70 — 60 45 30 25 — 110 110 60 50 — 25 25 15 15 —
CW060
Upflow
FLA 114.4 106.1 56.3 53.6 45.0 45.0 40.6 22.0 20.9 19.9 87.8 83.9 44.1 40.7 31.5 18.4 18.4 9.8 8.0 6.4
WSA 143.0 132.6 70.4 67.0 56.3 56.3 50.8 27.5 26.1 24.9 109.8 104.9 55.1 50.9 39.4 20.7 20.7 11.0 9.0 7.2
OPD 150 150 80 70 60 50 50 25 30 25 110 110 60 60 40 25 25 15 15 15
CW076
FLA 124.1 119.2 63.1 58.7 48.1 45.0 40.6 22.0 19.6 18.0 97.5 97.0 50.9 47.1 36.5 18.4 18.4 9.8 8.0 6.4
WSA 155.1 149.0 78.9 73.4 60.1 56.3 50.8 27.5 24.5 22.5 121.9 121.3 63.6 58.9 45.6 20.7 20.7 11.0 9.0 7.2
OPD 175 150 80 80 70 50 50 25 20 25 125 125 70 60 50 25 25 15 15 15
CW084
FLA 124.1 119.2 63.1 58.7 48.1 45.0 40.6 22.0 19.6 18.0 97.5 97.0 50.9 47.1 36.5 18.4 18.4 9.8 8.0 6.4
WSA 155.1 149.0 78.9 73.4 60.1 56.3 50.8 27.5 24.5 22.5 121.9 121.3 63.6 58.9 45.6 20.7 20.7 11.0 9.0 7.2
OPD 175 150 80 80 70 50 50 25 20 25 125 125 70 60 50 25 25 15 15 15
CW089
Downflow
FLA — — — 58.7 48.1 — — — 19.6 18.0 — — — 47.1 36.5 — — — 8.0 6.4
WSA — — — 73.4 60.1 — — — 24.5 22.5 — — — 58.9 45.6 — — — 9.0 7.2
OPD — — — 80 70 — — — 20 25 — — — 60 50 — — — 15 15
CW106
FLA 133.3 128.4 68.0 62.7 51.3 54.2 49.8 26.9 23.6 21.2 106.7 106.2 55.8 51.1 39.7 27.6 27.6 14.7 12.0 9.6
WSA 166.6 160.5 85.0 78.4 64.1 67.8 62.3 33.6 29.5 26.5 133.4 132.8 69.8 63.9 49.6 29.9 29.9 15.9 13.0 10.4
OPD 175 175 90 80 70 70 70 35 30 30 150 150 70 70 50 35 35 20 15 15
CW114
FLA 133.3 128.4 68.0 62.7 51.3 54.2 49.8 26.9 23.6 21.2 106.7 106.2 55.8 51.1 39.7 27.6 27.6 14.7 12.0 9.6
WSA 166.6 160.5 85.0 78.4 64.1 67.8 62.3 33.6 29.5 26.5 133.4 132.8 69.8 63.9 49.6 29.9 29.9 15.9 13.0 10.4
OPD 175 175 90 80 70 70 70 35 30 30 150 150 70 70 50 35 35 20 15 15
CW146
Downflow
FLA — — — 61.8 50.7 — — — 22.7 20.6 — — — 50.2 39.1 — — — 11.1 9.0
WSA — — — 77.3 63.4 — — — 28.4 25.8 — — — 62.8 48.9 — — — 12.0 9.8
OPD — — — 80 70 — — — 30 30 — — — 70 50 — — — 15 15
CW181
Downflow
FLA — — — 66.3 54.3 — — — 27.2 24.2 — — — 54.7 42.7 — — — 15.6 12.6
WSA — — — 82.9 67.9 — — — 34.0 30.3 — — — 68.4 53.4 — — — 16.9 13.7
OPD — — — 90 70 — — — 35 35 — — — 70 60 — — — 20 15
CW300
Downflow
FLA— — ———————— — — ——————22.2—
WSA— — ———————— — — ——————23.1—
OPD— — ———————— — — ——————25—
CW400
Downflow
FLA— — ———————— — — ——————31.2—
WSA— — ———————— — — ——————32.5—
OPD— — ———————— — — ——————35—
