Emerson CW026 - Figure B-2 Dimensions-Liebert Air Economizer and Liebert CW Models CW106 D;114 D

Customer-supplied Equipment and Ductwork
97 Liebert
®
CW
™
System Design Manual
Figure B-2 Dimensions—Liebert Air Economizer and Liebert CW models CW106D/114D
Typical unit shown.
Refer to dimensions and layout for your unit.
Plenum
Front of CW Uni
t
Room Return Air Damper
76"
1930mm
36"
914mm
34"
864mm
1"
25mm
1"
25mm
22"
559mm
REAR VIEW LEFT SIDE
VIEW
TOP VIEW
FRONT VIEW (REF. ONLY)
1"
25mm
Duct Collar
12"
305mm
Outside Air Damper
30 1/16"
764mm
112"
2845mm
118"
2996mm
Duct Flange
2"
51mm
83"
2108mm
Access Panel for 2" (51mm) Pre-Filters
122"
3099mm
Front of unit
DPN003226
Rev. 1
