Emerson CW026 - Table A-6 Upflow Liebert CW Models Direct Mount to Concrete Without Plenum, CW026-CW114; Table A-7 Upflow Liebert CW Models Direct Mount to Concrete with 36 Plenum, CW026-CW114

Optional Configuration for Liebert CW Seismic Application
Liebert
®
CW
™
System Design Manual 84
Table A-6 Upflow Liebert CW models direct mount to concrete without plenum, CW026-CW114
Model Number
Operating
Mass *
Restraint
Locations
Maximum Load per Anchor
Anchors
per LocationTension Shear
CW026-CW041UCS 909 6 664.5 192.5 1
CW051-CW060UCS 1241 6 919.3 258.6 1
CW076-CW084UCS 1519 6 1074.2 303.9 1
CW089-CW114UCS 2065 6 1094.7 398 1
* Operating mass includes the operating water volume, floor stand and plenum.
Table A-7 Upflow Liebert CW models direct mount to concrete with 36" plenum, CW026-CW114
Model Number
Operating
Mass *
Restraint
Locations
Maximum Load per Anchor
Anchors
per LocationTension Shear
CW026-CW041UCS 1065 6 929.8 226 1
CW051-CW060UCS 1461 6 1280.9 305.5 1
CW076-CW084UCS 1780 6 1498 355.9 1
CW089-CW114UCS 2400 6 1491.5 458.6 1
* Operating mass includes the operating water volume, floor stand and plenum.
