Safety
information
Product
information
Mechanical
installation
Electrical
installation
Getting
started
User Menu A Commissioning
Advanced
Parameters
Diagnostics Optimization CT MODBUS RTU Technical Data
44 E300 Design Guide
Issue Number: 1
Figure 3-21 Installing the gasket
To seal the space between the drive and the backplate, use two sealing brackets as shown in Figure 3-22.
Figure 3-22 Through panel mounting
Drive
Gasket
Enclosure
rear wall
Through panel
securing bracket
Enclosure
rear wall
Through panel
securing bracket
