Emerson Process Management GmbH & Co. OHG2-24
X-STREAM X2FD
Instruction Manual
HASXMDE-IM-EX
01/2015
After all connections are established in the
specifi ed manner, and verifi ed,
• fi x the cables according to the installation
instruction given in the cable glands / con-
duits manufacturer documentation.
• All cable entries must be sealed by me-
ans of either Ex d approved cable glands,
conduits or sealing plugs.
• Install the analyzer´s cover by means of
ALL 20 screws!
2.5 Installation - Electrical
EXPLOSION HAZARD
Do NOT operate the instrument with doors, sealing plugs or covers open!
This is permitted only when no hazardous atmosphere is present!
Depending on the local regulation, this may require a competent hot work
supervisor to issue a hot work permit.
Use ALL 20 screws to fi x the cover! Violation may cause an explosion!
ELECTRICAL SHOCK HAZARD
Before completing the electrical connection of the instrument, verify cables
are inserted and connected in correct manner!
Ensure the earthing conductor (protective earth; PE) is connected!
Tightening torque:
25 Nm (221 in.lb)
