X-STREAM X2FD
Instruction Manual
HASXMDE-IM-EX
01/2015
3
Startup
3.5 The user interface
All X-STREAM gas analyzers have an al-
phanumeric display with four lines of 20
characters to display measuring and status
information and the easy-to-use menu-based
user interface for entering parameters. For
ease of understanding, the user can at any
time select one of three languages stored in
the unit (currently available: English, French,
German, Italian and Spanish in various com-
binations).
Fig. 3-2: Front Panel
3.5 The user interface
Units are operated using six keys on the front
panel.
Three LEDs on the front panel enable the
operating status to be recognised instantly.
