Startup
3.9 Checking the settings
Check the settings for the measurement dis-
play, temperature and pressure units, and for
menu access: use the DOWN and ETER keys
to access the submenus
.
If a setting is not in accordance with your
requirements, access that menu ad adjust
the parameter.
Press the LEFT key to return to the display
setup
menu.
3.9.2 Confi guring the display
Line 1: Comp-1
Line 2: Comp-2
Line 3: Comp-3
Line 4: Comp-4
Page 2
Select the value to be displayed in each line
of the measurement display. The following
options are available:
Comp-1 ... Comp-4,
Temp-1 ... Temp-4,
Press-1 ... Press-4,
Flow-1 ... Flow-4
Blank (nothing)
Note!
X-STREAM currently supports only one pres-
sure sensor. Values Press-1 to Press-4 thus
refer to the same sensor .
Setup..
Display..
Component..
Temperature..
Pressure..
Gasfl ow..
Page 3
The measurement units for the displayed
values can be changed in the submenus on
page 3.
For example, here are the options for the
display of temperature values:
Temperature
Unit: °C
DecimalPlaces: 1
Temp-1 63.7 °C
Current temperature; here: sensor 1.
Set temperature unit
Options available: °C, °F
Set number of decimal places for temperature
display: 0 to 4
To Next Page
