Emerson Process Management GmbH & Co. OHG3-4
X-STREAM X2FD
Instruction Manual
HASXMDE-IM-EX
01/2015
3.4 Symbols used
3.4 Symbols used
Symbols and conventions used in the fol-
lowing sections
Symbol Meaning
Within descriptions of procedures
Setup..
Menu title
Setup..
Analog outputs..
Parent (Setup) and current
Menu (Analog outputs)
Analog outputs..
Output1 (2...4)
As an example, the menu
for Output1 is displayed;
the menus for outputs 2 to
4 are identical
Zero calibration..
Span calibration..
Adv. Calibration..
Apply gas..
Display
Note!
Menus or lines on a grey
background are optional or
context-dependent, and are
not always displayed
Access levels:
Access level 1
(user)
Access level 2
(expert)
Access level 3
(administrator)
Access level 4
(service level)

App
l
y
g
as.
.
Convention Meaning
Within descriptions
(Menu title)
6.2.2, page 6-12
For a detailed description
of this Menü, see section
6.2.2 on page 6-12
CONTROL - ZOOM..
Navigate from the main
menu via the CONTROL
menu to the ZOOM.. menu
„Valves“ Parameter name
Never, 1 min Selectable values
0 ... 2000 Range of values
In the following sections, the symbols and
typographical conventions described below
are used to describe the software menus and
navigation.
