3.9 Checking the settings
The cursor is now in the “In/Outputs” line
over an arrowhead. Press the DOWN key
to display the next menu page and open the
INSTALLED OPTIONS submenu.
InstalledOptions..
Communication..
Alarms..
Save-Load..
Press the LEFT key several times to return to
the SETUP menu.
This menu is in two columns and indicates
which of the possible optional components
are installed in the unit. The values displayed
on your unit may differ from those illustrated
here.
Do not edit any entries in these
menus without special know-
ledge.
Incorrect entries may result in
incorrect results or impair the
performance of the unit.
This initial access to this menu
is intended to gain information
on the confi guration of the unit.
3.9.1 Installed options
All X-STREAM gas analyzers can be fi tted
with a variety of optional components: follow
these steps to see which options are installed
on your analyzer.
Valves: Internal
COM-Interf: Yes
Pump: Yes
Flow monitor: Yes
Page 1
Page 2
DigitalIO: 1
Pressure: Internal
Analog outputs 4
More..
Protocol: MODB RTU
MODB Mode: 32Bit
ID number: 2
Interface: RS485/2w
Baud rate: 19200
Parity: No
In the two pages of the COMMUNICATION
menu, you can verify the parameters of the
serial interface, and if necessary select the
protocol to be used for data transfer.
Press the LEFT key twice to return to the
SETUP menu.
