Emerson Process Management GmbH & Co. OHG 3-29
X-STREAM X2FD
Instruction Manual
HASXMDE-IM-EX
01/2015
3
Startup
3.9 Checking the settings
Level1: 100 ppm
Function: Low
Level2: 500 ppm
Function: High
Press the LEFT key until the SETUP menu
is displayed, then select “Alarms” and open
the submenu. If you are using a multi-channel
analyzer, select the channel to be modifi ed.
3.9.5 Setting concentration alarms
Two concentration limits can be set for each
channel. Valid settings for limit levels depend
on the measuring range and the value of the
“SpanRange” parameter (
next page):
An error message is displayed if an invalid
setting is input.
Note!
If concentration alarms are not being used,go
straight to page 5-34.
Should the measured concentration go bey-
ond one of the limits, a message is displayed
in the fourth line of the measurement display
and the corresponding digital output is acti-
vated if programmed to do so.
