Emerson X-STREAM XE - Page 191

Emerson Process Management GmbH & Co. OHG 6-29
X-STREAM XE
Instruction Manual
HASXEE-IM-HS
10/2012
6
Software Menus
Display 1 Assignments
Line 1: Comp1
Line 2: Comp2
Line 3: Comp3
Line 4: Comp4
Line 5: Flow1
Labels..
6.2.3.1.3 Measurement Display Setup Menu
6.2.3 Setup Menu
Enter this menu to congure the measurement
display.
The MEASUREMENT DISPLAY may be
congured as a single or dual page version,
where the content of each page can be con-
gured separately by a related page within
this setup menu.
The rst setup menu page ('Display 1 ...') con-
gures the rst MEASUREMENT DISPLAY
page. You may specify up to 5 measurements
to be shown on the page. If only up to two pri-
mary and one secondary measurements are
congured, the display will use the 2 lines lay-
out with bigger characters. Enter the second
menu page ('Display 2 assignments') to setup
a second MEASUREMENT DISPLAY page.
If the system is setup accordingly, the access
code for level 2 must be entered to gain ac-
cess to this menu.
Setup..
Display..
Measurement Display..
On either setup menu page, highlight the line
to be congured, press enter and then select
the parameter to be displayed in the related
line by means of up / down.
Available options:
Comp1 ... Comp5
Temp1 ... Temp5
Flow1 ... Flow5
Press1 ... Press5
CalcA ... CalcD
Blank
Congure the labels 6-30.
Display 1 Assignments
Line 1: Comp1
Line 2: Comp2
Line 3: Comp3
Line 4: Comp4
Line 5: Blank
Labels..
 Display 2 Assignments
Line 1: Comp1
Line 2: Comp2
Line 3: Comp3
Line 4: Comp4
Line 5: Blank
Labels..
Note!
Primary measurements are gas measure-
ments. Secondary measurements are pres-
sure, ow, temperature; these are always
displayed with the smaller font.
