General Operating Notes
GENERAL OPERATING NOTES
• The unit must be installed in a clean and dry area protected from strong vibrations and
frost
.
• The unit must not be exposed to direct sunlight and sources of heat. Admissable ambient
temperatures (see technical details) must be adhered to.
• Gas inlets and outlets must not be interchanged.All gases must be supplied to the unit already
processed. When using this unit with corrosive sample gases, ensure that these gases do
not contain components harmful to the gas lines.
• Admissable gas pressure for sample and test gases is 1500 hPa.
• Exhaust lines must be laid inclined downwards, depressurized, protected from frost and
according to applicable regulations.
• If it is necessary to disconnect the gas lines, the unit’s gas connectors must be sealed with
PVC caps to avoid polluting the internal gas lines with condensate, dust, etc.
• To ensure electromagnetic compatibility (EMC), only shielded cables (supplied by us on re-
quest, or of equivalent standard) may be used. The customer must ensure that the shielding
is correctly tted. Shielding and terminal housing must be electrically connected; submin-D
plugs and sockets must be screwed to the unit.
• When using optional external adapters (submin-D to screw-type terminal), protection from
electromagnetic interference can no longer be guaranteed (CE compliance pursuant to EMC
guidelines). In this case the customer or operating company functions as a system builder
and must therefore ensure and declare compliance with EMC guidelines.
EXPLOSION HAZARD
Exhaust gases may contain hydrocarbons and other toxic gases such as
carbon monoxide. Carbon monoxide is toxic.
Faulty gas connections may lead to explosion and death.
Ensure that all gas connections are connected as labelled and airtight.
