Emerson X-STREAM XE - Page 301

Emerson Process Management GmbH & Co. OHG 7-13
X-STREAM XE
Instruction Manual
HASXEE-IM-HS
10/2012
7
Maintenance & Procedures
7.4.1 Preparing a Calibration
7.4.1.1.2 External Valve to Digital Output Assignment
If your analyzer has to control external valves,
at rst check if all valves required for calibra-
tion are connected to digital outputs.
Then open SETUP - IN/OUTPUTS - DIGITAL
OUTPUTS, to software assign the valves to
the outputs:
Further pages are indicated by a down arrow
(  ), only when at least one extension card
(outputs 5 - 13) is installed:
This menu congures the digital outputs: All
outputs (default and optional) support the
same range of signals/functions. Outputs 1
to 4 are available in every unit, and by default
setup to provide NAMUR signals (see gures
to the left).
Outputs 5 - 13 are present on the rst exten-
sion card,labelled X4.1 (outputs 9 to 13 setup
on separate
menu pages are not shown in
this example).
Note!
Depending on the analyzer model, 1 or 2
Digital I/O extension cards can be installed.
Setup..
In-/Outputs..
Digital Outputs..
 Digital Outputs (X4.1) 1of3
Output5 Node: System
Output5 Signal: Off
Output6 Node: System
Output6 Signal: Off
Output7 Node: System
Output7 Signal:
Off
 Digital Outputs (X4.1) 2of3
Output8 Node: System
Output8 Signal: Off
Output9 Node: System
Output9 Signal: Off
Output10 Node: System
Output10 Signal:
Off
 Digital Outputs (X4.1) 3of3
Output11 Node: System
Output11 Signal: Off
Output12 Node: System
Output12 Signal: Off
Output13 Node: System
Output13 Signal:
Off
Digital Outputs (X1)
Output1 Node: System
Output1 Signal: Off
Output2 Node: System
Output2 Signal: Off
Output3 Node: System
Output3 Signal: Off
Output4 Node: System
Output4 Signal:
Off
