Emerson X-STREAM XE - Page 434

Emerson Process Management GmbH & Co. OHG9-20
X-STREAM XE
Instruction Manual
HASXEE-IM-HS
10/2012
9.3 List of Parameters and Registers - Sorted by Tag Name
Tag Name Address
Data
Type
Client
Access
Description
Modicon Daniel
Setup.Display.MeasDisplay.Dis1Line1 3091 3091 Word R/W
assigned signal of measure display 1,
Line 1
Setup.Display.MeasDisplay.Dis1Line2 3092 3092 Word R/W
assigned signal of measure display 1,
Line 2
Setup.Display.MeasDisplay.Dis1Line3 3093 3093 Word R/W
assigned signal of measure display 1,
Line 3
Setup.Display.MeasDisplay.Dis1Line4 3094 3094 Word R/W
assigned signal of measure display 1,
Line 4
Setup.Display.MeasDisplay.Dis1Line5 3095 3095 Word R/W
assigned signal of measure display 1,
Line 5
Setup.Display.MeasDisplay.Dis2Label1
3121…
3124
3121…
3124
String R/W
displayed label of measure display 2,
Line 1
Setup.Display.MeasDisplay.Dis2Label2
3125…
3128
3125…
3128
String R/W
displayed label of measure display 2,
Line 2
Setup.Display.MeasDisplay.Dis2Label3
3129…
3132
3129…
3132
String R/W
displayed label of measure display 2,
Line 3
Setup.Display.MeasDisplay.Dis2Label4
3133…
3136
3133…
3136
String R/W
displayed label of measure display 2,
Line 4
Setup.Display.MeasDisplay.Dis2Label5
3137…
3140
3137…
3140
String R/W
displayed label of measure display 2,
Line 5
Setup.Display.MeasDisplay.Dis2Line1 3096 3096 Word R/W
assigned signal of measure display 2,
Line 1
Setup.Display.MeasDisplay.Dis2Line2 3097 3097 Word R/W
assigned signal of measure display 2,
Line 2
Setup.Display.MeasDisplay.Dis2Line3 3098 3098 Word R/W
assigned signal of measure display 2,
Line 3
Setup.Display.MeasDisplay.Dis2Line4 3099 3099 Word R/W
assigned signal of measure display 2,
Line 4
Setup.Display.MeasDisplay.Dis2Line5 3100 3100 Word R/W
assigned signal of measure display 2,
Line 5
Setup.In/Outputs.AO.AdjustEnd1
6367…
6368
9184 Float R/W
ne adjustment for end range of out-
put1
Setup.In/Outputs.AO.AdjustEnd2
6375…
6376
9188 Float R/W
ne adjustment for end range of out-
put2
Setup.In/Outputs.AO.AdjustEnd3
6383…
6384
9192 Float R/W
ne adjustment for end range of out-
put3
Setup.In/Outputs.AO.AdjustEnd4
6391…
6392
9196 Float R/W
ne adjustment for end range of out-
put4
Setup.In/Outputs.AO.AdjustEnd5
6399…
6400
9200 Float R/W
ne adjustment for end range of out-
put5
Setup.In/Outputs.AO.AdjustStart1
6365…
6366
9183 Float R/W
ne adjustment for start range of
output1
Setup.In/Outputs.AO.AdjustStart2
6373…
6374
9187 Float R/W
ne adjustment for start range of
output2
Setup.In/Outputs.AO.AdjustStart3
6381…
6382
9191 Float R/W
ne adjustment for start range of
output3
