Emerson X-STREAM XE User Manual

Emerson Process Management GmbH & Co. OHG 9-29
X-STREAM XE
Instruction Manual
HASXEE-IM-HS
10/2012
9
Modbus Commands
Tag Name Address
Data
Type
Client
Access
Description
Modicon Daniel
Setup.Measurement.XIntf.SignalValues1
6601…
6608
9301…
9304
Float RO
Cross interfere signal values1..4 for
comp1
Setup.Measurement.XIntf.SignalValues2
6661…
6668
9331…
9334
Float RO
Cross interfere signal values1..4 for
comp2
Setup.Measurement.XIntf.SignalValues3
6721…
6728
9361…
9364
Float RO
Cross interfere signal values1..4 for
comp3
Setup.Measurement.XIntf.SignalValues4
6781…
6788
9391…
9394
Float RO
Cross interfere signal values1..4 for
comp4
Setup.Measurement.XIntf.SignalValues5
6841…
6848
9421…
9424
Float RO
Cross interfere signal values1..4 for
comp5
Setup.Measurement.XIntf.Sources1
3481…
3484
3481…
3484
Word R/W
Interf. sources 1..4 comp1 (0=None
1=Conc1 2=Conc2 6=AIN1 etc.)
Setup.Measurement.XIntf.Sources2
3485…
3488
3485…
3488
Word R/W
Interf. sources 1..4 comp2 (0=None
1=Conc1 2=Conc2 6=AIN1 etc.)
Setup.Measurement.XIntf.Sources3
3489…
3492
3489…
3492
Word R/W
Interf. sources 1..4 comp3 (0=None
1=Conc1 2=Conc2 6=AIN1 etc.)
Setup.Measurement.XIntf.Sources4
3493…
3496
3493…
3496
Word R/W
Interf. sources 1..4 comp4 (0=None
1=Conc1 2=Conc2 6=AIN1 etc.)
Setup.Measurement.XIntf.Sources5
3497…
3500
3497…
3500
Word R/W
Interf. sources 1..4 comp5 (0=None
1=Conc1 2=Conc2 6=AIN1 etc.)
Status.CalcResultA
6091…
6092
9046 Float RO Result of calculator A
Status.CalcResultB
6093…
6094
9047 Float RO Result of calculator B
Status.CalcResultC
6095…
6096
9048 Float RO Result of calculator C
Status.CalcResultD
6097…
6098
9049 Float RO Result of calculator D
Status.DeviceStates.AnyCalib 1001 1001 Boolean RO Any calibration in progress
Status.DeviceStates.ChannelState1
5191…
5198
8096…
8099
DWord RO component1's state biteld (b0:......)
Status.DeviceStates.ChannelState2
5201…
5208
8101…
8104
DWord RO component2's state biteld (b0:......)
Status.DeviceStates.ChannelState3
5211…
5218
8106…
8109
DWord RO component3's state biteld (b0:......)
Status.DeviceStates.ChannelState4
5221…
5228
8111…
8114
DWord RO component4's state biteld (b0:......)
Status.DeviceStates.ChannelState5
5231…
5238
8116…
8119
DWord RO component5's state biteld (b0:......)
Status.DeviceStates.DeviceState
5181…
5188
8091…
8094
DWord RO device (N0) state biteld (b0:......)
Status.Diagnostics.AfterLinConce1
6909…
6910
9455 Float RO after linear. conc component1
Status.Diagnostics.AfterLinConce2
6923…
6924
9462 Float RO after linear. conc component2
Status.Diagnostics.AfterLinConce3
6937…
6938
9469 Float RO after linear. conc component3
9.3 List of Parameters and Registers - Sorted by Tag Name
