Modbus Commands
9.3 List of Parameters and Registers - Sorted by Tag Name
Tag Name Address
Data
Type
Client
Access
Description
Modicon Daniel
Status.Diagnostics.RawQuotConce3
6015…
6016
9008 Float RO raw ADC quotient of component3
Status.Diagnostics.RawQuotConce4
6017…
6018
9009 Float RO raw ADC quotient of component4
Status.Diagnostics.RawQuotConce5
6019…
6020
9010 Float RO raw ADC quotient of component4
Status.Diagnostics.RawRefConce1
6023…
6024
9012 Float RO raw ADC of reference side component1
Status.Diagnostics.RawRefConce2
6027…
6028
9014 Float RO raw ADC of reference side component2
Status.Diagnostics.RawRefConce3
6031…
6032
9016 Float RO raw ADC of reference side component3
Status.Diagnostics.RawRefConce4
6035…
6036
9018 Float RO raw ADC of reference side component4
Status.Diagnostics.RawRefConce5
6039…
6040
9020 Float RO raw ADC of reference side component5
Status.Flow1
6071…
6072
9036 Float RO ow of comp1
Status.Flow2
6073…
6074
9037 Float RO ow of comp2
Status.Flow3
6075…
6076
9038 Float RO ow of comp3
Status.Flow4
6077…
6078
9039 Float RO ow of comp4
Status.Flow5
6079…
6080
9040 Float RO ow of comp5
Status.IO.InputState1 4037 4037 Word RO Input state of a Digital Input Card #1
Status.IO.InputState2 4039 4039 Word RO Input state of a Digital Input Card #2
Status.IO.OutputState1 4036 4036 Word RO Output state of a XDIO Card #1
Status.IO.OutputState2 4038 4038 Word RO Output state of a XDIO Card #2
Status.IO.PSAOutputState 4035 4035 Word RO DOut state of a PSA Card
Status.IO.PSASHSState 4040 4040 Word
RO state of a PSA Card's SHS
Status.IO.ValveState
5361…
5362
8181 DWord RO
Valve state biteld (b0=V1, b1=V2, ....
b19=V20)
Status.NamurStates.FailAlarmComp1
5049…
5050
8025 DWord RO
NamurFailure alarms that are compo-
nent1 related
Status.NamurStates.FailAlarmComp2
5057…
5058
8029 DWord RO
NamurFailure alarms that are compo-
nent2 related
Status.NamurStates.FailAlarmComp3
5065…
5066
8033 DWord RO
NamurFailure alarms that are compo-
nent3 related
Status.NamurStates.FailAlarmComp4
5073…
5074
8037 DWord RO
NamurFailure alarms that are compo-
nent4 related
