Modbus Commands
Tag Name Address
Data
Type
Client
Access
Description
Modicon Daniel
Status.NamurStates.NamurAlarmCh1 4003 4003 Word RO
comp1's NAMUR state bit-eld (b0:F
b1:M b2:S b3:C)
Status.NamurStates.NamurAlarmCh2 4004 4004 Word RO
comp2's NAMUR state bit-eld (b0:F
b1:M b2:S b3:C)
Status.NamurStates.NamurAlarmCh3 4005 4005 Word RO
comp3's NAMUR state bit-eld (b0:F
b1:M b2:S b3:C)
Status.NamurStates.NamurAlarmCh4 4006 4006 Word RO
comp4's NAMUR state bit-eld (b0:F
b1:M b2:S b3:C)
Status.NamurStates.NamurAlarmCh5 4007 4007 Word RO
comp4's NAMUR state bit-eld (b0:F
b1:M b2:S b3:C)
Status.NamurStates.NamurAlarmDevice 4002 4002 Word RO
device's NAMUR state bit-eld (b0:F
b1:M b2:S b3:C)
Status.NamurStates.OffSpecActive
5011…
5012
8006 DWord RO Namur Off-spec active biteld
Status.NamurStates.OffSpecAlarm
5003…
5004
8002 DWord RO Namur Off-spec alarm biteld
Status.NamurStates.OffSpecAlarmComp1
5051…
5052
8026 DWord RO
Namur Off-spec alarms that are com-
ponent1 related
Status.NamurStates.OffSpecAlarmComp2
5059…
5060
8030 DWord RO
Namur Off-spec alarms that are com-
ponent2 related
Status.NamurStates.OffSpecAlarmComp3
5067…
5068
8034 DWord RO
Namur Off-spec alarms that are com-
ponent3 related
Status.NamurStates.OffSpecAlarmComp4
5075…
5076
8038 DWord RO
Namur Off-spec alarms that are com-
ponent4 related
Status.NamurStates.OffSpecAlarmComp5
5083…
5084
8042 DWord RO
Namur Off-spec alarms that are com-
ponent5 related
Status.NamurStates.OffSpecAlarmDev
5043…
5044
8022 DWord RO
NamurOff-spec alarms that are device
related
Status.Pressure1
6061…
6062
9031 Float RO pressure of comp1
Status.Pressure2
6063…
6064
9032 Float RO pressure of comp2
Status.Pressure3
6065…
6066
9033 Float RO pressure of comp3
Status.Pressure4
6067…
6068
9034 Float RO pressure of comp4
Status.Pressure5
6069…
6070
9035 Float RO pressure of comp5
Status.Temperature1
6081…
6082
9041 Float RO temperature of comp1
Status.Temperature2
6083…
6084
9042 Float RO temperature of comp2
9.3 List of Parameters and Registers - Sorted by Tag Name
