Modbus Commands
9.4 List of Parameters and Registers - Sorted by Daniel Registers
Address Tag Name
Data
Type
Client
Access
Description
Daniel Modicon
3214 3214 Setup.In/Outputs.SHS.Signal_Gas4 Word R/W signal of SHS GasOut4
3215 3215 Setup.In/Outputs.SHS.Signal_Gas5 Word R/W signal of SHS GasOut5
3216 3216 Setup.In/Outputs.SHS.Signal_Gas6 Word R/W signal of SHS GasOut6
3217 3217 Setup.In/Outputs.SHS.Signal_Gas7 Word R/W signal of SHS GasOut7
3218 3218 Setup.In/Outputs.SHS.Signal_Gas8 Word R/W signal of SHS GasOut8
3219 3219
Setup.In/Outputs.SHS.Signal_
Pump1
Word R/W signal of SHS Pump1
3220 3220
Setup.In/Outputs.SHS.Signal_
Pump2
Word R/W signal of SHS Pump1
3221 3221 Setup.In/Outputs.DI.Node_DI1 Word R/W node of DigInp1 / XDIO1 Inp1
3222 3222 Setup.In/Outputs.DI.Node_DI2 Word R/W node of DigInp2 / XDIO1 Inp2
3223 3223 Setup.In/Outputs.DI.Node_DI3 Word R/W node of DigInp3 / XDIO1 Inp3
3224 3224 Setup.In/Outputs.DI.Node_DI4 Word R/W node of DigInp4 / XDIO1 Inp4
3225 3225 Setup.In/Outputs.DI.Node_DI5 Word R/W node of DigInp5 / XDIO1 Inp5
3226 3226 Setup.In/Outputs.DI.Node_DI6 Word R/W node of DigInp6 / XDIO1 Inp6
3227 3227 Setup.In/Outputs.DI.Node_DI7 Word R/W node of DigInp7 / XDIO1 Inp7
3228 3228 Setup.In/Outputs.DI.Signal_DI1 Word R/W signal of DigInp1 / XDIO1 Inp1
3229 3229 Setup.In/Outputs.DI.Signal_DI2 Word R/W signal of DigInp2 / XDIO1 Inp2
3230 3230 Setup.In/Outputs.DI.Signal_DI3 Word R/W signal of DigInp3 / XDIO1 Inp3
3231 3231 Setup.In/Outputs.DI.Signal_DI4 Word R/W signal of DigInp4 / XDIO1 Inp4
3232 3232 Setup.In/Outputs.DI.Signal_DI5 Word R/W signal of DigInp5 / XDIO1 Inp5
3233 3233 Setup.In/Outputs.DI.Signal_DI6 Word R/W signal of DigInp6 / XDIO1 Inp6
3234 3234 Setup.In/Outputs.DI.Signal_DI7
Word R/W signal of DigInp7 / XDIO1 Inp7
3235 3235 Service.IO.InputSimVal1 Word R/W Simulation Input state of a XDIO Card #1
3236 3236 Setup.In/Outputs.DI.Node_DI8 Word R/W node of DigInp8 / XDIO2 Inp1
3237 3237 Setup.In/Outputs.DI.Node_DI9 Word R/W node of DigInp9 / XDIO2 Inp2
3238 3238 Setup.In/Outputs.DI.Node_DI10 Word R/W node of DigInp10 / XDIO2 Inp3
3239 3239 Setup.In/Outputs.DI.Node_DI11 Word R/W node of DigInp11 / XDIO2 Inp4
3240 3240 Setup.In/Outputs.DI.Node_DI12 Word R/W node of DigInp12 / XDIO2 Inp5
3241 3241 Setup.In/Outputs.DI.Node_DI13 Word R/W node of DigInp13 / XDIO2 Inp6
3242 3242 Setup.In/Outputs.DI.Node_DI14 Word R/W node of DigInp14 / XDIO2 Inp7
3243 3243 Setup.In/Outputs.DI.Signal_DI8 Word R/W signal of DigInp8 / XDIO2 Inp1
3244 3244 Setup.In/Outputs.DI.Signal_DI9 Word R/W signal of DigInp9 / XDIO2 Inp2
3245 3245 Setup.In/Outputs.DI.Signal_DI10 Word R/W signal of DigInp10 / XDIO2 Inp3
3246 3246 Setup.In/Outputs.DI.Signal_DI11 Word R/W signal of DigInp11 / XDIO2 Inp4
3247 3247 Setup.In/Outputs.DI.Signal_DI12 Word R/W signal of DigInp12 / XDIO2 Inp5
3248 3248 Setup.In/Outputs.DI.Signal_DI13 Word R/W signal of DigInp13 / XDIO2 Inp6
3249 3249 Setup.In/Outputs.DI.Signal_DI14 Word R/W signal of DigInp14 / XDIO2 Inp7
3250 3250 Service.IO.InputSimVal2 Word R/W Simulation Input state of a XDIO Card #2
3270 3270 Setup.In/Outputs.AO.NumberOuts Word R/W number of analog outputs
3271 3271 Setup.In/Outputs.AO.SignalAsgn1 Word R/W assigned signal output1
3272 3272 Setup.In/Outputs.AO.OutRange1 Word R/W range of output1 (0=0..20mA 1=4-20mA)
3273 3273 Setup.In/Outputs.AO.AutoScale1 Word R/W
Auto scale for ranged signals on output1 (0=N0
1=Yes)
