9.4 List of Parameters and Registers - Sorted by Daniel Registers
Address Tag Name
Data
Type
Client
Access
Description
Daniel Modicon
3274 3274 Setup.In/Outputs.AO.FailMode1 Word R/W
Behavior on errors output1 (0=Track 1=-10%Start
2=+10%End)
3275 3275 Setup.In/Outputs.AO.Hold1 Word R/W Hold output1 on calibrations (0=Track 1=Hold)
3276 3276 Setup.In/Outputs.AO.SignalAsgn2 Word R/W assigned signal output2
3277 3277 Setup.In/Outputs.AO.OutRange2 Word R/W range of output2 (0=0..20mA 1=4-20mA)
3278 3278 Setup.In/Outputs.AO.AutoScale2 Word R/W
Auto scale for ranged signals on output2 (0=N0
1=Yes)
3279 3279 Setup.In/Outputs.AO.FailMode2 Word R/W
Behavior on errors output2 (0=Track 1=-10%Start
2=+10%End)
3280 3280 Setup.In/Outputs.AO.Hold2 Word R/W Hold output2 on calibrations (0=Track 1=Hold)
3281 3281 Setup.In/Outputs.AO.SignalAsgn3 Word R/W assigned signal output3
3282 3282 Setup.In/Outputs.AO.OutRange3 Word R/W range of output3 (0=0..20mA 1=4-20mA)
3283 3283 Setup.In/Outputs.AO.AutoScale3 Word R/W
Auto scale for ranged signals on output3 (0=N0
1=Yes)
3284 3284 Setup.In/Outputs.AO.FailMode3 Word R/W
Behavior on errors output3 (0=Track 1=-10%Start
2=+10%End)
3285 3285 Setup.In/Outputs.AO.Hold3 Word R/W Hold output3 on calibrations (0=Track 1=Hold)
3286 3286 Setup.In/Outputs.AO.SignalAsgn4 Word R/W assigned signal output4
3287 3287 Setup.In/Outputs.AO.OutRange4 Word R/W range of output4 (0=0..20mA 1=4-20mA)
3288 3288 Setup.In/Outputs.AO.AutoScale4 Word R/W
Auto scale for ranged signals on output4 (0=N0
1=Yes)
3289 3289 Setup.In/Outputs.AO.FailMode4 Word R/W
Behavior on errors output4 (0=Track 1=-10%Start
2=+10%End)
3290 3290 Setup.In/Outputs.AO.Hold4 Word R/W Hold output4 on calibrations (0=Track 1=Hold)
3291 3291 Setup.In/Outputs.AO.SignalAsgn5 Word R/W assigned signal output5
3292 3292 Setup.In/Outputs.AO.OutRange5 Word R/W range of output5 (0=0..20mA 1=4-20mA)
3293 3293 Setup.In/Outputs.AO.AutoScale5 Word
R/W
Auto scale for ranged signals on output5 (0=N0
1=Yes)
3294 3294 Setup.In/Outputs.AO.FailMode5 Word R/W
Behavior on errors output5 (0=Track 1=-10%Start
2=+10%End)
3295 3295 Setup.In/Outputs.AO.Hold5 Word R/W Hold output5 on calibrations (0=Track 1=Hold)
3296 3296 Setup.In/Outputs.AO.CutMode1 Word R/W Cut mode on output1 (0=Standard 1=Cong)
3297 3297 Setup.In/Outputs.AO.CutMode2 Word R/W Cut mode on output2 (0=Standard 1=Cong)
3298 3298 Setup.In/Outputs.AO.CutMode3 Word R/W Cut mode on output3 (0=Standard 1=Cong)
3299 3299 Setup.In/Outputs.AO.CutMode4 Word R/W Cut mode on output4 (0=Standard 1=Cong)
3300 3300 Setup.In/Outputs.AO.CutMode5 Word R/W Cut mode on output5 (0=Standard 1=Cong)
3301 3301 Setup.Calibration.ZeroMethod1 Word R/W zero cal method comp1 (0=Instant, 1=Stability)
3302 3302 Setup.Calibration.ZeroMethod2 Word R/W zero cal method comp2 (0=Instant, 1=Stability)
3303 3303 Setup.Calibration.ZeroMethod3 Word R/W zero cal method comp3 (0=Instant, 1=Stability)
3304 3304 Setup.Calibration.ZeroMethod4 Word R/W zero cal method comp4 (0=Instant, 1=Stability)
3305 3305 Setup.Calibration.ZeroMethod5 Word R/W zero cal method comp5 (0=Instant, 1=Stability)
3306 3306 Setup.Calibration.SpanMethod1 Word R/W span cal method comp1 (0=Instant, 1=Stability)
3307 3307 Setup.Calibration.SpanMethod2 Word R/W span cal method comp2 (0=Instant, 1=Stability)
3308 3308 Setup.Calibration.SpanMethod3 Word R/W span cal method comp2 (0=Instant, 1=Stability)
3309 3309 Setup.Calibration.SpanMethod4 Word R/W span cal method comp4 (0=Instant, 1=Stability)
