Emerson Process Management GmbH & Co. OHG9-38
X-STREAM XE
Instruction Manual
HASXEE-IM-HS
10/2012
9.4 List of Parameters and Registers - Sorted by Daniel Registers
Address Tag Name
Data
Type
Client
Access
Description
Daniel Modicon
3172 3172 Setup.In/Outputs.DO.Signal_DO6 Word R/W signal of DigOut6 / XDIO1 Out2
3173 3173 Setup.In/Outputs.DO.Signal_DO7 Word R/W signal of DigOut7 / XDIO1 Out3
3174 3174 Setup.In/Outputs.DO.Signal_DO8 Word R/W signal of DigOut8 / XDIO1 Out4
3175 3175 Setup.In/Outputs.DO.Signal_DO9 Word R/W signal of DigOut9 / XDIO1 Out5
3176 3176 Setup.In/Outputs.DO.Signal_DO10 Word R/W signal of DigOut10 / XDIO1 Out6
3177 3177 Setup.In/Outputs.DO.Signal_DO11 Word R/W signal of DigOut11 / XDIO1 Out7
3178 3178 Setup.In/Outputs.DO.Signal_DO12 Word R/W signal of DigOut12 / XDIO1 Out8
3179 3179 Setup.In/Outputs.DO.Signal_DO13 Word R/W signal of DigOut13 / XDIO1 Out9
3180 3180 Service.IO.InputSimEnable1 Word R/W Enable Inputs Simulation of XDIO Card #1
3181 3181 Setup.In/Outputs.DO.Node_DO14 Word R/W node of DigOut14 / XDIO2 Out1
3182 3182 Setup.In/Outputs.DO.Node_DO15 Word R/W node of DigOut15 / XDIO2 Out2
3183 3183 Setup.In/Outputs.DO.Node_DO16 Word R/W node of DigOut16 / XDIO2 Out3
3184 3184 Setup.In/Outputs.DO.Node_DO17 Word R/W node of DigOut17 / XDIO2 Out4
3185 3185 Setup.In/Outputs.DO.Node_DO18 Word R/W node of DigOut18 / XDIO2 Out5
3186 3186 Setup.In/Outputs.DO.Node_DO19 Word R/W node of DigOut19 / XDIO2 Out6
3187 3187 Setup.In/Outputs.DO.Node_DO20 Word R/W node of DigOut20 / XDIO2 Out7
3188 3188 Setup.In/Outputs.DO.Node_DO21 Word R/W node of DigOut21 / XDIO2 Out8
3189 3189 Setup.In/Outputs.DO.Node_DO22 Word R/W node of DigOut22 / XDIO2 Out9
3191 3191 Setup.In/Outputs.DO.Signal_DO14 Word R/W signal of DigOut14 / XDIO2 Out1
3192 3192 Setup.In/Outputs.DO.Signal_DO15 Word R/W signal of DigOut15 / XDIO2 Out2
3193 3193 Setup.In/Outputs.DO.Signal_DO16 Word R/W
signal of DigOut16 / XDIO2 Out3
3194 3194 Setup.In/Outputs.DO.Signal_DO17 Word R/W signal of DigOut17 / XDIO2 Out4
3195 3195 Setup.In/Outputs.DO.Signal_DO18 Word R/W signal of DigOut18 / XDIO2 Out5
3196 3196 Setup.In/Outputs.DO.Signal_DO19 Word R/W signal of DigOut19 / XDIO2 Out6
3197 3197 Setup.In/Outputs.DO.Signal_DO20 Word R/W signal of DigOut20 / XDIO2 Out7
3198 3198 Setup.In/Outputs.DO.Signal_DO21 Word R/W signal of DigOut21 / XDIO2 Out8
3199 3199 Setup.In/Outputs.DO.Signal_DO22 Word R/W signal of DigOut22 / XDIO2 Out9
3200 3200 Service.IO.InputSimEnable2 Word R/W Enable Inputs Simulation of XDIO Card #2
3201 3201 Setup.In/Outputs.SHS.Node_Gas1 Word R/W node of SHS GasOut1
3202 3202 Setup.In/Outputs.SHS.Node_Gas2 Word R/W node of SHS GasOut2
3203 3203 Setup.In/Outputs.SHS.Node_Gas3 Word R/W node of SHS GasOut3
3204 3204 Setup.In/Outputs.SHS.Node_Gas4 Word R/W node of SHS GasOut4
3205 3205 Setup.In/Outputs.SHS.Node_Gas5 Word R/W node of SHS GasOut5
3206 3206 Setup.In/Outputs.SHS.Node_Gas6 Word R/W node of SHS GasOut6
3207 3207 Setup.In/Outputs.SHS.Node_Gas7 Word R/W node of SHS GasOut7
3208 3208 Setup.In/Outputs.SHS.Node_Gas8 Word R/W node of SHS GasOut8
3209 3209
Setup.In/Outputs.SHS.Node_
Pump1
Word R/W node of SHS Pump1
3210 3210
Setup.In/Outputs.SHS.Node_
Pump2
Word R/W node of SHS Pump1
3211 3211 Setup.In/Outputs.SHS.Signal_Gas1 Word R/W signal of SHS GasOut1
3212 3212 Setup.In/Outputs.SHS.Signal_Gas2 Word R/W signal of SHS GasOut2
3213 3213 Setup.In/Outputs.SHS.Signal_Gas3 Word R/W signal of SHS GasOut3
