Emerson X-STREAM XE User Manual

Emerson Process Management GmbH & Co. OHG9-60
X-STREAM XE
Instruction Manual
HASXEE-IM-HS
10/2012
Address Tag Name
Data
Type
Client
Access
Description
Daniel Modicon
4059…
4062
4059…
4062
Setup.Measurement.XIntf.Signal-
States3
Word RO Cross interfere signal value states1..4 for comp3
4063…
4066
4063…
4066
Setup.Measurement.XIntf.Signal-
States4
Word RO Cross interfere signal value states1..4 for comp4
4067…
4070
4067…
4070
Setup.Measurement.XIntf.Signal-
States5
Word RO Cross interfere signal value states1..4 for comp5
8091…
8094
5181…
5188
Status.DeviceStates.DeviceState DWord RO device (N0) state biteld (b0:......)
8096…
8099
5191…
5198
Status.DeviceStates.Channel-
State1
DWord RO component1's state biteld (b0:......)
8101…
8104
5201…
5208
Status.DeviceStates.Channel-
State2
DWord RO component2's state biteld (b0:......)
8106…
8109
5211…
5218
Status.DeviceStates.Channel-
State3
DWord RO component3's state biteld (b0:......)
8111…
8114
5221…
5228
Status.DeviceStates.Channel-
State4
DWord RO component4's state biteld (b0:......)
8116…
8119
5231…
5238
Status.DeviceStates.Channel-
State5
DWord RO component5's state biteld (b0:......)
8121…
8124
5241…
5248
Service.Status.DeviceStates.Dvc-
StateInhibit
DWord R/W Inhibit for device (N0) state biteld (b0:......)
8126…
8129
5251…
5258
Service.Status.DeviceStates.
ChStateInhibit1
DWord R/W Inhibit for comp1's state biteld (b0:......)
8131…
8134
5261…
5268
Service.Status.DeviceStates.
ChStateInhibit2
DWord R/W Inhibit for comp2's state biteld (b0:......)
8136…
8139
5271…
5278
Service.Status.DeviceStates.
ChStateInhibit3
DWord R/W Inhibit for comp3's state biteld (b0:......)
8141…
8144
5281…
5288
Service.Status.DeviceStates.
ChStateInhibit4
DWord R/W Inhibit for comp4's state biteld (b0:......)
8146…
8149
5291…
5298
Service.Status.DeviceStates.
ChStateInhibit5
DWord R/W Inhibit for comp5's state biteld (b0:......)
8151…
8154
5301…
5308
Service.Status.DeviceStates.Dvc-
StateForce
DWord R/W Forcing for device (N0) state biteld (b0:......)
8156…
8159
5311…
5318
Service.Status.DeviceStates.
ChStateForce1
DWord R/W Forcing for comp1's state biteld (b0:......)
8161…
8164
5321…
5328
Service.Status.DeviceStates.
ChStateForce2
DWord R/W Forcing for comp2's state biteld (b0:......)
8166…
8169
5331…
5338
Service.Status.DeviceStates.
ChStateForce3
DWord R/W Forcing for comp3's state biteld (b0:......)
8171…
8174
5341…
5348
Service.Status.DeviceStates.
ChStateForce4
DWord R/W Forcing for comp4's state biteld (b0:......)
8176…
8179
5351…
5358
Service.Status.DeviceStates.
ChStateForce5
DWord R/W Forcing for comp5's state biteld (b0:......)
9171…
9178
6341…
6356
Service.Measurement.Simulation.
XSPMuxValue1
Float RO values for XSP's multiplexer value1..8
9201…
9204
6401…
6408
Service.Measurement.Compensa-
tion.ToffCoeffs1
Float R/W polynom coeffs for temperature offset of comp1
9.4 List of Parameters and Registers - Sorted by Daniel Registers
