Emerson Process Management GmbH & Co. OHG A-17
X-STREAM XE
Instruction Manual
HASXEE-IM-HS
10/2012
A
Appendix
A.3 CSA Certicate of Compliance
Certificate:
1714037 (LR 105173)
Master Contract:
185562
Project:
2507282
Date Issued:
March 14, 2012
DQD 507 Rev. 2009-09-01 Page: 4
X-Stream FD (X2FD) has same electronics as the X-STREAM General Purpose Gas Analyzer (X2GP) with
new Hazardous Locations Enclosure.
X2FD-abcdefghijklmnopqrstuv
a = Language: A, B, C, D, E or F
b = Ambient Conditions: 1, 2, 3, 4, 5 or 6
c = Instrument: 01, 02, 03, 04, 05, 06, 07, 08, 09, 10, 11, 12, 13, 14 or 15
d = Bench 1: any combination of 2 or 3 alpha-numeric characters
e = Bench 1 – Special Linearization or Calibration: 0, 1, 2, 3, 4, 5, A, B, C or D
f = Bench 2: any combination of 2 or 3 alpha-numeric characters
g = Bench 2 – Special Linearization or Calibration: 0, 1, 2, 3, 4, 5, A, B, C or D
h = Bench 3: any combination of 2 or 3 alpha-numeric characters
i = Bench 3 – Special Linearization or Calibration: 0, 1, 2, 3, 4, 5, A, B, C or D
j = Bench 4: any combination of 2 or 3 alpha-numeric characters
k = Bench 4 – Special Linearization or Calibration: 0, 1, 2, 3, 4, 5, A, B, C or D
l = Enclosure: 1, 2, 3, 4, 5 or 6
m = Hazardous Area Options and Special Approvals: B or D
B = CSA Certification
D = CSA Certification with a Breathing Device for Venting (Same Device as option “v”)
n = Analog Outputs: 1, 2, 3 or 4
o = Digital Inputs/Relay Outputs: 0, 1 or 2
p = Communication Interface: 0, A, B, C or D
q = Spare: 0
r = Sample Handling: 0, 1, 2, 3, 4, 5 or 6
s = Gas Path Sensors: 0, 1, 2, 3, 4, 5, 6, 7 or 8
t = Gas Path Tubing: A, B, C, D, E, F, G, H or I
