Emerson Process Management GmbH & Co. OHG 2-13
X-STREAM XE
Instruction Manual
HASXEE-IM-HS
10/2012
2
Technical Data
2.2.2 Model-Specic Technical Data: X-STREAM XEGP
Temperatures
operational, max.
*)
0 … +50 °C / 32 … 122 °F
storage -20 … +70 °C / -4 … -158 °F
Weight, max 12 … 16 kg / 26.5 … 35.3 lb
IP or Type rating
IP 20 for indoor use,
protected against dripping water and direct sun light
Measurement channels, max. 5
Gas connections
max number 8
max for purging
(incl. / separate)
1 separate.
material PVDF; stainless steel (opt.)
sizes 6/4 mm;
1
4"
Power supply unit wide range, internal
Power supply
Mains supply voltage uctuations are not to exceed
± 10 percent of the nominal voltage
nominal voltage 100–240 V
50 / 60 Hz
voltage range 85264 V
4763 Hz
nominal input current, max
standard, max 1.3–0.7 A
w/ temperature control, max 3–1.5 A
Power input fuses AC 230 V / T 4 A / 5x20 mm
Electrical in- and outputs
power IEC connector with integrated power switch & fuse holders
signals
signal cables are connected using submin-D plugs or so-
ckets on the unit’s rear panel
optional
terminals adaptors, to be installed onto the submin-D con-
nectors
special Ethernet: RJ45 socket; USB connectors
*)
: Limitations apply to selected measurement principles and ranges,
Measurement specications!
