CG Drives & Automation 01-7318-01r1 Functional description 125
11.11.4 Reactive power (Q)
controller parameters [O40]
Q Max limit [O41]
Reactive power max. limit value, i.e. amount of unused
capacity that is allowed for Q - compensation.
Q ramp time [O41]
Q ramp time, defined as time from 0->100%.
Q PI Gain [O43]
Q PI controller P gain.
Q PI Time [O44]
Q PI controller I time.
Q Filter time [O45]
Q filter time in dynamic/static feedback loop.
Default: 0%
Range 0 to 100%
NOTE:
Reactive power limited internally by the amount of
actual active power.
Default: 1s
Range 0.0 - 10.0s
Default: 0.10
Range 0.00 - 1.00
Default: 0.1s
Range 0.0 - 10.0s
Default: 1s
Range 0.0 - 10.0s
