Emotron AFR 2.0 Series User Manual

128 Functional description CG Drives & Automation 01-7318-01r1
2nd Stage Grid Code Over Voltage Protec-
tion level [G114]
Trip level for second stage grid code over voltage protection.
2nd Stage Grid Code Over Voltage
Protection Trip Time [G115]
Trip time for second stage grid code over voltage protection.
1st Stage Grid Code Under Voltage Protec-
tion level [G116]
Trip level for first stage grid code under voltage protection.
1st Stage Grid Code Under Voltage
Protection Trip Time [G117]
Trip time for first stage grid code under voltage protection.
2nd Stage Grid Code Under Voltage
Protection level [G118]
Trip level for second stage grid code under voltage
protection.
2nd Stage Grid Code Under Voltage
Protection Trip Time [G119]
Trip time for second stage grid code under voltage
protection.
Grid Code Voltage Protection Voltage
Hysteresis [G11A]
This voltage hysteresis setting is common (applicable) to all
grid code voltage protections.
Grid Code Voltage Protection Reset Time
[G11B]
This reset time setting is common (applicable) to all grid
code voltage protections.
Grid Code Positive Sequence Over Voltage
Protection level [G11C]
Trip level for grid code +ve sequence over voltage protection.
Default: 120.0%
Range: 100.0% - 200.0%
Default: 0.20 s
Range:
0=Off
0.01 s - 60.00 s
Default: 85.0%
Range: 0.0% - 100.0%
Default: 1.50s
Range:
0 = Off
0.01s - 60.00s
Default: 80.0%
Range: 0.0% - 100.0%
G114 3U>> Level
Stp 120.0%
G115 3U>> Time
Stp 0.20s
G116 3U< Level
Stp 85.0%
G117 3U< Time
Stp 1.50s
G118 3U<< Level
Stp 80.0%
Default: 0.20s
Range:
0=Off
0.01s - 60.00s
Default: 2.0%
Range: 0.0% - 100.0%
Default: 1.00s
Range:
0=Off
0.00s - 60.00s
Default: 110.0%
Range: 100.0% - 200.0%
G119 3U<< Time
Stp 0.20s
G11A U Hysteres
Stp 2.0%
G11B U Rst Time
Stp 1.00s
G11C U+> Level
Stp 110.0%
