Grid Code Positive Sequence Over Voltage
Protection Trip Time [G11D]
Trip time for grid code +ve sequence over voltage protection.
Grid Code Positive Sequence Under Voltage
Protection level [G11E]
Trip level for grid code +ve sequence under voltage
protection.
Grid Code Positive Sequence Under Voltage
Protection Trip Time [G11F]
Trip time for grid code +ve sequence under voltage
protection.
Grid Code Negative Sequence Over Voltage
Protection level [G11G]
Trip level for grid code -ve sequence over voltage protection.
Grid Code Negative Sequence Over Voltage
Protection Trip Time [G11H]
Trip time for grid code -ve sequence over voltage protection.
Grid Code Zero Sequence Over Voltage Pro-
tection level [G11I]
Trip level for grid code zero sequence over voltage
protection.
Grid Code Zero Sequence Over Voltage Pro-
tection Trip Time [G11J]
Trip time for grid code zero sequence over voltage
protection.
Grid Code 10-Minute Mean Over Voltage
Protection level [G11K]
Trip level for grid code 10-minute mean over voltage
protection.
Default: Off
Range:
0=Off
0.01s - 60.00s
Default: 85.0%
Range: 0.0% - 100.0%
Default: Off
Range:
0=Off
0.01s - 60.00s
Default: 5.0%
Range: 0.0% - 100.0%
G11D U+> Time
Stp Off
G11E U+< Level
Stp 85.0%
G11F U+< Time
Stp Off
G11G U-> Level
Stp 5.0%
Default: Off
Range:
0=Off
0.01s - 60.00s
Default: 10.0%
Range: 0.0% - 100.0%
Default: Off
Range:
0=Off
0.01s - 60.00s
Default: 110.0%
Range: 100.0% - 200.0%
G11H U-> Time
Stp Off
G11I U0> Level
Stp 10.0%
G11J U0> Time
Stp Off
G11K Umean> Lvl
Stp 110.0%
