2nd Stage Grid Code Over Frequency
Protection level [G124]
Trip level for second stage grid code over frequency
protection.
2nd Stage Grid Code Over Frequency
Protection Trip Time [G125]
Trip time for second stage grid code over frequency
protection.
1st Stage Grid Code Under Frequency
Protection level [G126]
Trip level for first stage grid code under frequency
protection.
1st Stage Grid Code Under Frequency
Protection Trip Time [G127]
Trip time for first stage grid code under frequency
protection.
2nd Stage Grid Code Under Frequency
Protection level [G128]
Trip level for second stage grid code under frequency
protection.
2nd Stage Grid Code Under Frequency
Protection Trip Time [G129]
Trip time for second stage grid code under frequency
protection.
Grid Code Frequency Protection Frequency
Hysteresis [G12A]
This frequency hysteresis setting is common (applicable) to
all grid code frequency protections.
Grid Code Frequency Protection Reset Time
[G12B]
This reset time setting is common (applicable) to all grid
code frequency protections.
Default: 105.0%
Range: 100.0% - 200.0%
Default: 0.20s
Range:
0 = Off
0.01s - 60.00s
Default: 98.0%
Range: 0.0% - 100.0%
Default: 1.50s
Range:
0 = Off
0.01s - 60.00s
G124 F>> Level
Stp 105.0%
G125 F>> Time
Stp 0.20s
G126 F< Level
Stp 98.0%
G127 F< Time
Stp 1.50s
Default: 95.0%
Range: 0.0% - 100.0 %
Default: 0.20s
Range:
0 = Off
0.01s - 60.00s
Default: 0.2%
Range: 0.0% - 100.0%
Default: 1.00s
Range:
0=Off
0.00s - 60.00s
G128 F<< Level
Stp 95.0%
G129 F<< Time
Stp 0.20s
G12A F Hysteres
Stp 0.2%
G12B F Rst Time
Stp 1.00s
