Emotron AFR 2.0 Series User Manual

CG Drives & Automation 01-7318-01r1 195
G128 F<< Level 95.0% 48237 189/41 UInt, 1=0.1% UInt 131
G129 F<< Time 0.20s 48238 189/42 UInt, 1=0.01s UInt 131
G12A F Hysteres 0.2% 48239 189/43 UInt, 1=0.1% UInt 131
G12B F Rst Time 1.00s 48240 189/44 UInt, 1=0.01s UInt 131
G13 GCP ROCOF 132
G131 ROCOF Level 2.00%/s 48245 189/49
UInt, 1=0.01%/s UInt 132
G132 ROCOF Time 2.00s 48246 189/50 UInt, 1=0.01s UInt 132
G133 ROCOF Hyst 0.02%/s 48247 189/51 UInt, 1=0.01%/s UInt 132
G134 ROCOF Rst T 1.00s 48248 189/52 UInt, 1=0.01s UInt 132
G20 GC Q ctrl 132
G21 Q mode Off 48251 189/55 UInt, 1=1 UInt 132
G22 Q fix 132
G221 Q max oe 50% 48255 189/59 Int, 1=1% Int 132
G222 Q max ue -50% 48256 189/60 Int, 1=1% Int 133
G23 CosΦ fix 133
G231 CosΦ min oe 0.90 48258 189/62 Int, 1=0.01 Int 133
G232 CosΦ min ue -0.90 48259 189/63 Int, 1=0.01 Int 133
G24 Q(U) 133
G241 Q1 50% 48261 189/65 Int, 1=1% Int 133
G242 U1 85% 48265 189/69 UInt, 1=1% UInt 134
G243 Q2 10% 48262 189/66 Int, 1=1% Int 134
Menu
Parameters
Default settings
Modbus
Instance/
DeviceNet No.
Profibus
slot/
index
EtherCAT
Index
(HEX)
Profinet
index
Fieldbus format
Modbus
format
Page Remarks
