Emotron AFR 2.0 Series User Manual

196 CG Drives & Automation 01-7318-01r1
G244 U2 95% 48266 189/70 UInt, 1=1% UInt 134
G245 Q3 -10% 48263 189/67 Int, 1=1% Int 134
G246 U3 105% 48267 189/71 UInt, 1=1% UInt 134
G247 Q4 -50% 48264 189/68 Int, 1=1% Int 134
G248 U4 110% 48268 189/72 UInt, 1=1% UInt 134
G249 Filt time 3.0s 48269 189/73 UInt, 1=0.1s UInt 134
G24A Cosφ min 0.01 48270 189/74 Int, 1=0.01 Int 135
G24B P lock In 10% 48301 189/105 UInt, 1=1% UInt 135
G24C P lock out 0% 48302 189/106 UInt, 1=1% UInt 135
G25 CosΦ(U) 135
G251 CosΦ1 0.9 48271 189/75 Int, 1=0.01 Int 135
G252 U1 85% 48275 189/79 UInt, 1=1% UInt 135
G253 CosΦ2 0.95 48272 189/76 Int, 1=0.01 Int 135
G254 U2 95% 48276 189/80 UInt, 1=1% UInt 136
G255 CosΦ3 -0.95 48273 189/77 Int, 1=0.01 Int 136
G256 U3 105% 48277 189/81 UInt, 1=1% UInt 136
G257 CosΦ4 -0.90 48274 189/78 Int, 1=0.01 Int 136
G258 U4 110% 48278 189/82 UInt, 1=1% UInt 136
G259 Filt time 3.0s 48279 189/83 UInt, 1=0.1s UInt 136
G25B P lock In 10% 48306 189/110 UInt, 1=1% UInt 136
G25C P lock out 0% 48307 189/111 UInt, 1=1% UInt 136
Menu
Parameters
Default settings
Modbus
Instance/
DeviceNet No.
Profibus
slot/
index
EtherCAT
Index
(HEX)
Profinet
index
Fieldbus format
Modbus
format
Page Remarks
