Emotron AFR 2.0 Series User Manual

138 Functional description CG Drives & Automation 01-7318-01r1
Feed In Active Power level (P4) [G268]
Feed in active power (P4) level at which specified Q4 is
supplied.
Filter Time Constant On Active Power
Calculations [G269]
Calculated feed in active power (P) used for Q(P) support
has a first order filter. Time constant for that first order filter
can be configured here. This is common time constant for
all the active power levels i.e. P1, P2, P3 and P4.
Cos Φ control as a function of feed in
active power Cos
Φ (P) [G27]
Displacement power factor (CosΦ) at the terminals of AFE/
AFG can also be configured as a function of feed in active
power. Characteristics of displacement power factor (CosΦ)
as a function of feed in active power can be configured using
four configurable points. For details read section Reactive
power (Q) support, section 7.17.2. In this menu, settings
related to CosΦ -P characteristic curve can be configured.
Displacement power factor (CosΦ1) At
Active Power Level (P1) [G271]
Desired displacement power factor (CosΦ1) at calculated
feed in active power (P1) level.
Feed In Active Power level (P1) [G272]
Feed in active power (P1) level at which specified CosΦ1 is
maintained.
Displacement power factor (CosΦ2) At
Active Power Level (P2) [G273]
Desired displacement power factor (CosΦ2) at calculated
feed in active power (P2) level.
Feed In Active Power level (P2) [G274]
Feed in active power (P2) level at which specified CosΦ2 is
maintained.
Displacement power factor (CosΦ3) At
Active Power Level (P3) [G275]
Desired displacement power factor (CosΦ3) at calculated
feed in active power (P3) level.
Default: 100%
Range: 0% - 100%
Default: 3.0s
Range: 0.0s - 60.0s
Default: 0.90
Range: -1.00 - 1.00
NOTE:
-ve Cos
Φ1 value in [G271] indicates the under excited
(Q-absorbed) mode and +ve sign indicates the over-
excited (Q-delivered) mode.
G268 P4
Stp 100%
G269 Filt time
Stp 3.0s
G271 CosΦ1
Stp 0.90
Default: 25%
Range: 0% - 100%
Default: 0.70
Range: -1.00 - 1.00
NOTE:
-ve CosΦ2 value in [G273] indicates the under excited
(Q-absorbed) mode and +ve sign indicates the over-
excited (Q-delivered) mode.
Default: 50%
Range: 0% - 100%
Default: 0.88
Range: -1.00 - 1.00
NOTE:
-ve Cos
Φ3 value in [G275] indicates the under excited
(Q-absorbed) mode and +ve sign indicates the over-
excited (Q-delivered) mode.
G272 P1
Stp 25%
G273 CosΦ2
Stp 0.70
G274 P2
Stp 50%
G275 CosΦ3
Stp 0.88
