142 Functional description CG Drives & Automation 01-7318-01r1
Trip UV t2 [G32F]
UVRT trip-curve [2] time.
In Fig. 44, t2 = Off means that UVRT trip area [2] is
inactivated.
Trip UV U2 [G32G]
UVRT trip-curve [2] voltage.
In Fig. 44, UVRT trip area [2] is defined as the area to the
right of the linear line from [t1,U1] to [t2,U2] (and if
selection t1=Off then area on the right of line from [t2,0] to
[t2,U2]).
Trip OV t1 [G32H]
OVRT trip-curve [1] time.
Selection t1=Off means that OVRT trip area [1] in Fig. 44 is
inactivated.
Trip OV U1 [G32I]
OVRT trip-curve [1] voltage.
In Fig. 44, OVRT trip area [1] is defined as the area above
the horizontal line from [t(fault),U1] to [t1,U1].
Trip OV t2 [G32J]
OVRT trip-curve [2] time.
In Fig. 44, t2 = Off means that OVRT trip area [2] is
inactivated.
Trip OV U2 [G32K]
OVRT trip-curve [2] voltage.
In Fig. 44, OVRT trip area [2] is defined as the area to the
right of the linear line from [t1,U1] to [t2,U2] (and if
selection t1=Off then area on the right of line from
[t2,140%] to [t2,U2]).
GC AID [G33]
This menu contain parameters related to anti-islanding
detection (AID) settings.
Passive AID [G331]
Enable/disable the passive AID method.
Active AID [G332]
Enable/disable the active AID method.
Default: 3.00s
Range: 0.01s - 60.00s
Default: 85%
Range: 0% - 100%
Default: 0.10s
Range: 0.01s - 60.00s
Default: 130%
Range: 100% - 140%
Default: 0.10s
Range: 0.01s - 60.00s
Default: 120%
Range: 100% - 140%
Default: Off
Off 0 Disable
On 1 Enable
Default: Off
Off 0 Disable
On 1 Enable
NOTE:
Contact local supplier or authorized Emotron service
personal if further assistance is required with AID
detection.
