94 Functional description CG Drives & Automation 01-7318-01r1
GCP Trigg< 23
Grid Code Protections (GCP) under-
trips condition trigged (condition for
GCP tripping met).
LY 24 Logic output Y.
!LY 25 Logic output Y inverted.
LZ 26 Logic output Z.
!LZ 27 Logic output Z inverted.
CA 1 28 Analogue comparator 1 output.
!A1 29 Analogue comp 1 inverted output.
CA 2 30 Analogue comparator 2 output.
!A2 31 Analogue comp 2 inverted output.
CD 1 32 Digital comparator 1 output.
!D1 33 Digital comp 1 inverted output.
CD2 34 Digital comparator 2 output.
!D2 35 Digital comp 2 inverted output.
Operation 36
Run command is active or AC drive
running. The signal can be used to
control the mains contactor if the AC
drive is equipped with Standby
supply option.
T1Q 37 Timer1 output
!T1Q 38 Timer1 inverted output
T2Q 39 Timer2 output
!T2Q 40 Timer2 inverted output
Loc/Rem 57
Local/Rem mode indication
Local = 1, Remote = 0
Standby 58 Standby supply option is active
PTC Trip 59 Trip when function is active
PT100 Trip 60 Trip when function is active
Overvolt 61 Overvoltage due to high main voltage
Overvolt G 62 Overvoltage due to generation mode
Overvolt D 63 Overvoltage due to deceleration
I
2
t66I
2
t limit protection active
V-Limit 67 Overvoltage limit function active
C-Limit 68 Overcurrent limit function active
Overtemp 69 Over temperature warning
Low voltage 70 Low voltage warning
DigIn 1 71 Digital input 1
DigIn 2 72 Digital input 2
DigIn 3 73 Digital input 3
DigIn 4 74 Digital input 4
DigIn 5 75 Digital input 5
DigIn 6 76 Digital input 6
DigIn 7 77 Digital input 7
DigIn 8 78 Digital input 8
ManRst Trip 79
Active trip that needs to be manually
reset
Com Error 80 Serial communication lost
External Fan 81
The AC drive requires external
cooling. Internal fans are active.
LC Pump 82 Activate liquid cooling pump
LC HE Fan 83
Activate liquid cooling heat
exchanger fan
LC Level 84 Liquid cooling low level signal active
Com Active 87 Fieldbus communication active.
Option 90
Failure occurred in built-in option
board.
CA3 91 Analogue comparator 3 output
!A3 92
Analogue comparator 3 inverted
output
CA4 93 Analogue comparator 4 output
!A4 94
Analogue comparator 4 inverted
output
CD3 95 Digital comparator 3 output
!D3 96 Digital comparator 3 inverted output
CD4 97 Digital comparator 4 output
!D4 98 Digital comparator 4 inverted output
C1Q 99 Counter 1 output
!C1Q 100 Counter 1 inverted output
C2Q 101 Counter 2 output
!C2Q 102 Counter 2 Inverted output
CLK1 106
Clock 1 output signal (CLK1) is
activated.
!CLK1 107
Clock 1 output signal (CLK1) is not
activated.
CLK2 108
Clock 2 output signal (CLK2) is
activated.
!CLK2 109
Clock 2 output signal (CLK2) is not
activated.
Charge Relay 110
Signal / Digital output for controlling
charge contactor.
Main Relay 111
Signal/ Digital output for controlling
mains contactor.
Udc OK 112 AFR/AFG is up and running.
