CG Drives & Automation 01-7318-01r1 Functional description 93
AnOut2 Setup [535]
Preset scaling and offset of the output configuration for
analogue output 2.
AnOut2 Advanced [536]
Same functions and submenus as under AnOut1 Advanced
[533].
11.6.4 Digital Outputs [540]
Submenu with all the settings for the digital outputs.
Digital Out 1 [541]
Sets the function for the digital output 1.
Default: 4-20mA
Selection: Same as in menu
[532]
535 AnOut2 Setup
Stp 4-20mA
NOTE: The definitions described here are valid for the
active output condition.
Default: LY
Off 0
Output is not active and constantly
low.
On 1
Output is made constantly high, i.e.
for checking circuits and trouble
shooting.
Run 2
Running. The AC drive output is
active = produces current for the
motor.
Stop 3 The AC drive output is not active.
At Process 6 The output = Reference.
No Trip 8 No Trip condition active.
Trip 9 A Trip condition is active.
AutoRst Trip 10 Autoreset trip condition active.
Limit 11 A Limit condition is active.
Warning 12 A Warning condition is active.
Ready 13
The AC drive is ready for operation.
This means that the AC drive is
powered up and healthy.
T= T
lim
14
The torque is limited by the torque
limit function.
I>I
nom
15
The output current is higher than the
motor nominal current [224], reduced
according to Motor ventilation [228],
see Fig. , page 108.
Sgnl<Offset 17
One of the AnIn input signals is lower
than 75% of the threshold level.
GCP Trip 18
Grid Code Protections (GCP) trip
condition is active.
GCP Trigg 19
Grid Code Protections (GCP) trigged
(condition for tripping met).
GCP Trip> 20
Grid Code Protections (GCP) over-
trips condition is active.
GCP Trigg> 21
Grid Code Protections (GCP) over-
trips condition trigged (condition for
CGP tripping met).
GCP Trip< 22
Grid Code Protections (GCP) under-
trips condition is active.
