92 Functional description CG Drives & Automation 01-7318-01r1
AnOut1 Function Min [5334]
With AnOut1 Function Min the physical minimum value is
scaled to selected presentation. The default scaling is
dependent of the selected function of “AnOut1 [531]”.
Table 23 shows corresponding values for the min and max
selections depending on the function of the analogue output
[531].
*) Fmin is dependent on the set value in menu “Minimum
Speed [341]”.
Example
Set the AnOut function for Motorfrequency to 0Hz, set
AnOut functionMin [5334] to “User-defined” and AnOut1
VaMin[5335] = 0.0. This results in an anlogue output signal
from 0/4 mA to 20mA: 0Hz to Fmot.
This principle is valid for all Min to Max settings.
AnOut1 Function Value Min [5335]
With AnOut1 Function VaMin you define a user-defined
value for the signal. Only visible when user-defined is
selected in menu [5334].
AnOut1 Function Max [5336]
With AnOut1 Function Min the physical minimum value is
scaled to selected presentation. The default scaling is
dependent on the selected function of AnOut1 [531]. See
Table 23.
AnOut1 Function Value Max [5337]
With AnOut1 Function VaMax you define a user-defined
value for the signal. Only visible when user-defined is
selected in menu [5334].
AnOut2 Function [534]
Sets the function for the Analogue Output 2.
Default: Min
Min 0 Min value
Max 1 Max value
User defined 2 Define user value in menu [5335]
Ta b l e 2 3
AnOut
Function
Min Value Max Value
Process Value Process Min [324] Process Max [325]
Torque 0% Max Torque [351]
Process Ref Process Min [324] Process Max [325]
React Power 0% Motor Power [223]
Frequency Fmin * Motor Frequency [222]
Current 0 A Motor Current [224]
El Power 0 W Motor Power [223]
Output
Voltage
0 V Motor Voltage [221]
DC voltage 0 V 1000 V
AnIn1
AnIn1 Function
Min
AnIn1 Function Max
AnIn2
AnIn2 Function
Min
AnIn2 Function Max
AnIn3
AnIn3 Function
Min
AnIn3 Function Max
AnIn4
AnIn4 Function
Min
AnIn4 Function Max
Torque Ref 0% Max Torque [351]
Default: 0.000
Range: -10000.000–10000.000
Default: Max
Min 0 Min value
Max 1 Max value
User defined 2 Define user value in menu [5337]
NOTE:
It is possible to set AnOut1 up as an inverted output
signal by setting AnOut1 Min > AnOut1 Max. See Fig.
72, page 86.
Default: 0.000
Range: -10000.000–10000.000
Default: Torque
Selection: Same as in menu
[531]
5335 AnOut1VaMin
Stp 0.000
5337 AnOut1VaMax
Stp 0.000
