120 Functional Description Emotron AB 01-3694-01r2
Communication information
AnOut 1 Setup [532]
Preset scaling and offset of the output configuration.
Communication information
Fig. 103
AnOut1 Advanced [533]
With the functions in the AnOut1 Advanced menu, the out-
put can be completely defined according to the application
needs. The menus will automatically be adapted to “mA” or
“V”, according to the selection in AnOut1 Setup [532].
AnOut1 Min [5331]
This parameter is automatically displayed if User mA or
User V is selected in menu AnOut 1 Setup [532]. The menu
will automatically adapt to current or voltage setting accord-
ing to the selected setup. Only visible if [532] = User mA/V.
Communication information
AnOut1 Max [5332]
This parameter is automatically displayed if User mA or
User V is selected in menu AnOut1 Setup [532]. The menu
will automatically adapt to current or voltage setting accord-
ing to the selected setup. Only visible if [532] = User mA/V.
Modbus Instance no/DeviceNet no: 43251
Profibus slot/index 169/155
Fieldbus format UInt
Modbus format UInt
Default: 4-20mA
4–20mA 0
The current output has a fixed threshold
(Live Zero) of 4 mA and controls the full
range for the output signal. See Fig. 100.
0–20mA 1
Normal full current scale configuration of
the output that controls the full range for
the output signal. See Fig. 99.
User mA 2
The scale of the current controlled output
that controls the full range for the output
signal. Can be defined by the advanced
AnOut Min and AnOut Max menus.
User Bipol
mA
3
Sets the output for a bipolar current out-
put, where the scale controls the range
for the output signal. Scale can be
defined in advanced menu AnOut Bipol.
0-10V 4
Normal full voltage scale configuration of
the output that controls the full range for
the output signal. See Fig. 99.
2–10V 5
The voltage output has a fixed threshold
(Live Zero) of 2 V and controls the full
range for the output signal. See Fig. 100.
User V 6
The scale of the voltage controlled output
that controls the full range for the output
signal. Can be defined by the advanced
AnOut Min and AnOut Max menus.
User Bipol V 7
Sets the output for a bipolar voltage out-
put, where the scale controls the range
for the output signal. Scale can be
defined in advanced menu AnOut Bipol.
Modbus Instance no/DeviceNet no: 43252
Profibus slot/index 169/156
Fieldbus format UInt
Modbus format UInt
532 AnOut1 Setup
Stp 4-20mA
A
Default: 4 mA
Range: 0.00 – 20.00 mA, 0 – 10.00 V
Modbus Instance no/DeviceNet no: 43253
Profibus slot/index 169/157
Fieldbus format Long, 1=0.01
Modbus format EInt
Default: 20.00 mA
Range: 0.00–20.00 mA, 0–10.00 V
VSD 1
Master
VSD 2
Slave
Ref.
AnOut
Ref.
533 AnOut 1 Adv
Stp
A
5331 AnOut 1 Min
Stp 4mA
A
5332 AnOut 1 Max
Stp 20.0mA
