Emotron AB 01-3694-01r2 Getting Started 31
5.5 Local control
Manual control via the control panel can be used to carry
out a test run.
Use a 400 V motor and the control panel.
5.5.1 Switch on the mains
Close the door to the VSD. Once the mains is switched on,
the VSD is started and the internal fan will run for 5 sec-
onds.
5.5.2 Select manual control
Menu [100], Preferred View is displayed when started.
1. Press to display menu [200], Main Setup.
2. Press to display menu [210], Operation.
3. Press to display menu [211], Language.
4. Press to display menu [214], Reference Control.
5. Select Keyboard using the key and press to con-
firm.
6. Press to get to menu [215], Run/Stop Control.
7. Select Keyboard using the key and press to con-
firm.
8. Press to get to previous menu level and then to
display menu [220], Motor Data.
5.5.3 Set the Motor Data
Enter correct motor data for the connected motor.
9. Press to display menu [221].
10. Change the value using the and keys. Confirm
with .
11. Press to display menu [222].
12. Repeat step 9 and 10 until all motor data is entered.
13. Press twice and then to display menu [100], Pre-
ferred View.
5.5.4 Enter a Reference Value
Enter a reference value.
14. Press until menu [300], Process is displayed.
15. Press to display menu [310], Set/View reference
value.
16. Use the and keys to enter 300 rpm. We select a
low value to check the rotation direction without dam-
aging the motor.
5.5.5 Run the VSD
Press the key on the control panel to run the motor.
Whe the motor is running the main connections are OK.
ENTER
ENTER
ENTER
ENTER
ESC
ENTER
ENTER
ESC
ENTER
