Emotron AB 01-3694-01r2 Functional Description 143
11.9.2 Trip Messages [820] - [890]
Same information as for menu [810].
Communication information
All nine alarm lists contain the same type of data. For exam-
ple DeviceNet parameter 31101 in alarm list 1 contains the
same data information as 31151 in alarm list 2. It is possible
to read all parameters in alarm lists 2–9 by recalculating the
DeviceNet instance number into a Profibus slot/index
number. This is done in the following way:
slot no = abs((dev instance no-1)/255)
index no = (dev instance no-1) modulo 255
dev instance no = slot nox255+index no+1
Example: We want to read out the process value out from
alarm list 9. In alarm list 1 process value has the DeviceNet
instance number 31102. In alarm list 9 it has DeviceNet
instance no 31502 (see table 2 above). The corresponding
slot/index no is then:
slot no = abs((31502-1)/255)=123
index no (modulo)= the remainder of the division above =
136, calculated as: (31502-1)-123x255=136
11.9.3 Reset Trip Log [8A0]
Resets the content of the 10 trip memories.
Communication information
11.10 System Data [900]
Main menu for viewing all the VSD system data.
11.10.1 VSD Data [920]
VSD Type [921]
Shows the VSD type according to the type number.
The other options are indicated on the type plate of the
VSD.
Example of type
Communication information
Examples:
FDU40-073 VSD-series suited for 400 volt mains supply,
and a rated output current of 74 A.
Software [922]
Shows the software version number of the VSD.
Fig. 117 gives an example of the version number.
Fig. 117 Example of software version
Modbus Instance no/
DeviceNet no:
31151–31184
31201–31234
31251–31284
31301–31334
31351–31384
31401–31434
31451–31484
31501–31534
Trip log list
2
3
4
5
6
7
8
9
Profibus slot/index
122/40–122/73
122/90–122/123
122/140–122/173
122/190–122/223
122/240–123/18
123/35 - 123/68
123/85–123/118
123/135–123/168
Trip log list
2
3
4
5
6
7
8
9
Fieldbus format UInt
Modbus format UInt
Default: No
No 0
Yes 1
8A0 Reset Trip
Stp No
Modbus Instance no/DeviceNet no: 8
Profibus slot/index 0/7
Fieldbus format UInt
Modbus format UInt
NOTE: After the reset the setting goes automatically
back to “NO”. The message “OK” is displayed for 2 sec.
Modbus Instance no/DeviceNet no: 31037
Profibus slot/index 121/181
Fieldbus format Long
Modbus format Text
921 FDU2.0
Stp FDU40-004
922 Software
Stp V 4.03
