Emotron AB 01-3694-01r2 Functional Description 63
11. Functional Description
This chapter describes the menus and parameters in the soft-
ware. You will find a short description of each function and
information about default values, ranges, etc. There are also
tables containing communication information. You will find
the Modbus, DeviceNet and Fieldbus address for each
parameter as well as the enumeration for the data.
11.1 Resolution of settings
The resolution for all range settings described in this chapter
is 3 significant digits. Exceptions are speed values which are
presented with 4 significant digits. Table 21 shows the reso-
lutions for 3 significant digits.
11.2 Preferred View [100]
This menu is displayed at every power-up. During opera-
tion, the menu [100] will automatically be displayed when
the keyboard is not operated for 5 minutes. As default it dis-
plays the actual current.
Menu [100], Preferred View displays the settings made in
menu [110], 1st line, and [120], 2nd line. See Fig. 66.
Fig. 66 Display functions
11.2.1 1st Line [110]
Sets the content of the upper row in the menu [100] Pre-
ferred View
.
Communication information
11.2.2 2nd Line [120]
Sets the content of the lower row in the menu [100] Pre-
ferred View. Same selection as in menu [110].
NOTE: Functions marked with the sign cannot be
changed during Run Mode.
Ta b le 2 1
3 Digit Resolution
0.01-9.99 0.01
10.0-99.9 0.1
100-999 1
1000-9990 10
10000-99900 100
100 0rpm
Stp 0.0A
100 (1st Line)
Stp (2nd Line)
Default: Process Val
Dependent on menu
Process Val 0 Process value
Speed 1 Speed
Torque 2 Torque
Process Ref 3 Process reference
Shaft Power 4 Shaft power
El Power 5 Electrical power
Current 6 Current
Output volt 7 Output voltage
Frequency 8 Frequency
DC Voltage 9 DC voltage
Heatsink Tmp 10 Heatsink temperature
Motor Temp 11 Motor temperature
VSD Status 12 VSD status
Run Time 13 Run Time
Energy 14 Energy
Mains Time 15 Mains time
Modbus Instance no/DeviceNet no: 43001
Profibus slot/index 168/160
Fieldbus format UInt
Modbus format UInt
Default: Current
110 1st Line
Stp Process Val
120 2nd Line
Stp Current
